Float Switch Level Sensor

float switch, commonly used for liquid level sensing and control in tanks or reservoirs.

Key Components:

Yellow and red part: This is the float, which contains a microswitch. It floats on the surface of a liquid and tilts as the liquid level changes.

Black cable: Contains the electrical wires for connection to a control panel, pump, or alarm.

Black cylindrical part: This is typically a counterweight or stopper, used to adjust the length of the cable inside the tank, thereby setting the liquid level at which the switch operates.

Applications:

Water tanks

Sump pumps

Industrial fluid containers

Sewage systems
