Description

SPECIFICATION :- CABLE QUALITY :- Heavy Duty Natural Rubber Wire CABLE LENGTH :- 1,2,3,5,10,15,20... MTR ( 2 core 1.50 sq.mm. fully flexible wire) SWITCHING CURRENT :- 21(8)A, 250V~ 21A, 1HP, 125VAC; 2HP, 250VAC, 21A 1.5/2 HP - 125/250VAC* Ele. Temp. Rating: -40° to +85°C, 125°C or 150°C, Flammability Rating: UL94V-O SWITCH CURRENCY :- According to EN (Min. Operations) 10,000. According to UL (Min. Operations) 6,000. WORKING PRESSURE :- 2 Bar CHARACTERISTICS :- IP 65 , IP 67 & Mercury free operated Switch WEATHER RESISTANCE :- cables have good weather resistance, can work normally in the temp. range of -40°C to 90°C, and will not harden or deform due to temperature changes. Approved by :- SGS and NABL NOTES :- Warranty life time is waterproof * Standard cartoon One year against manufacturing defects. GST at actual 1,2,3,5 MTR @ 60 nos. Cartoon standard Fright at actual Payment 100% Advance. 10,15 MTR @ 36 nos. Cartoon standard Delivery Ex Stock MOQ 60 nos. Standard cartoon. (1 Box) 20, 25, 30 MTR @ 24 nos. Cartoon standard *Upgrade your water management systems with our trusted solutions! * The GELZON Level Regulator GCFL21AOBW pro is the ideal solution to control liquid levels in industrial applications such as: • Industrial waste water • Emulsion of oils • Many chemicals • Ideal for residential, commercial, and industrial use. • Suitable for automatic control of pumps in: • Water tanks • Sewage pumps • Aquaculture systems The GELZON level regulator GCFL21AOBW pro can be used everywhere where liquid levels must be supervised. The GCFL21AOBW pro is ideal for industrial applications. It is simple to install and maintenance-free. Thus, fast economical and reliable solutions can be realized. The GCFL21AOBW pro is equipped with GELZON‘s pro Resist cable which guarantees extreme durability and resistance. Different than the MS control switches, the GCFL21AOBW pro is a pump switch which can be used for direct control of pumps. The level controller GCFL21AOBW pro can also be supplied in combination with the GELZON contactor combination, the GELZON motor starter or the GELZON capacitor plug. Application: For direct pump control for example in industrial waste water, emulsions of oils and fats, diluted acids and brines, aggressive mediums. Safety Features: Overload protection and resistant to corrosion, ensuring longevity and safety in operation. All our products are genuine quality, ensuring safety and longevity. Quality Assurance: All products are manufactured under strict quality control measures to ensure reliability and performance.
